Introduction
GTI Technologies is one of the leading Drum Dryer manufacturers in India, engineering high-efficiency, continuous Single and Double Drum Dryers for processing liquids, slurries, pastes, suspensions, and viscous materials into powders, flakes, or granules.
Our Drum Dryers utilize indirect conductive heat transfer via steam-heated rotating drum surfaces. By spreading a thin liquid film over the heated drum, rapid evaporation occurs within seconds, followed by continuous removal of the dried film using precision doctor blades (knives).
Unlike direct hot air dryers, Drum Dryers transfer heat directly through the metal drum shell, eliminating the need for massive air volumes and complex dust recovery systems. This delivers:
Exceptional thermal efficiency
Ultra-fast drying times (seconds)
Minimal power and fuel consumption
Compact physical footprint
Gentle thermal treatment for heat-sensitive slurries
High product purity and low dust generation
Simple, continuous, one-step operation
GTI designs and manufactures Single Drum Dryers, Double Drum Dryers, and Twin Drum Dryers with capacities ranging from pilot-scale R&D units to heavy-duty continuous industrial production plants.
What is an Drum Dryer (Single / Double Drum)?
A Drum Dryer is a continuous, conductive, indirect drying machine featuring one or two internal steam-heated rotating cylinders (drums). The liquid, slurry, or paste feed is applied as a thin, uniform film over the outer revolving surface. Heat conducted through the drum shell rapidly evaporates moisture, leaving a dry layer that is continuously scraped off by adjustable doctor blades.
Single Drum Dryer
Features a single heated drum with feed application via dip pan, applicator rolls, or top feed rollers. Ideal for viscous pastes, heat-sensitive suspensions, gelatinized products, and heavy slurries requiring precise film control.
Double Drum Dryer
Features two parallel drums rotating toward each other with a narrow, adjustable gap (nip) between them. Liquid feed is poured into the sump formed between the drums. As they rotate, a thin film is drawn onto each drum, making it highly versatile for low-to-medium viscosity solutions, slurries, and sticky materials.
Working Principle of Continuous Drum Dryer (Single / Double Drum)?
Feed Application: Liquid, slurry, or solution enters the drum via dip tray, spray nozzles, applicator rolls, or the nip feed between double drums.
Thin Film Formation: A uniform, thin layer of liquid adheres smoothly across the outer surface of the steam-heated drum.
Rapid Indirect Heating: Steam inside the drum shell rapidly heats the drum wall, boiling off moisture in seconds as the cylinder rotates.
Vapor Removal: Vaporized moisture rises into a custom-designed exhaust hood and vapor recovery system.
Continuous Scraping: Before completing a full rotation, an adjustable doctor blade continuously scrapes the dry product off the drum surface in sheets, flakes, or powder.
Discharge & Sizing: The scraped material drops into a screw conveyor, flaker, or pulverizer for final particle sizing and packaging.
Advantages of Drum Dryer Technology
Industrial Drum Dryer offers unmatched flexibility and productivity across multiple industries.
Key Benefits
- ✓ One-Step Liquid-to-Powder Conversion
- ✓ Ultra-Fast Drying Time (5 to 30 Seconds)
- ✓ High Steam Thermal Efficiency
- ✓ Gentle Heat Treatment for Heat-Sensitive Products
- ✓ Compact Footprint Compared to Spray Dryers
- ✓ Low Operating & Maintenance Costs
- ✓ Adjustable Doctor Blade Pressure & Gap Control
- ✓ Continuous 24/7 Production Operation
- ✓ Sanitary & Hygienic Designs (CIP Compatible)
- ✓ Variable Drum Speed Control (VFD Included)
- ✓ Minimal Dust Emissions & Air Pollution
- ✓ Suitable for Sticky, Viscous, and High-Solids Slurries
Advantages of Drum Dryer Band Dryer Technology
- ✓ One-Step Liquid-to-Powder Conversion
- ✓ Ultra-Fast Drying Time (5 to 30 Seconds)
- ✓ High Steam Thermal Efficiency
- ✓ Gentle Heat Treatment for Heat-Sensitive Products
- ✓ Compact Footprint Compared to Spray Dryers
- ✓ Low Operating & Maintenance Costs
- ✓ Adjustable Doctor Blade Pressure & Gap Control
- ✓ Continuous 24/7 Production Operation
- ✓ Sanitary & Hygienic Designs (CIP Compatible)
- ✓ Variable Drum Speed Control (VFD Included)
- ✓ Minimal Dust Emissions & Air Pollution
- ✓ Suitable for Sticky, Viscous, and High-Solids Slurries
Technical Features
Precision-Machined & Micro-Polished Drum Shells
Chrome-Plated, Nickel-Plated, or Hard-Faced Drum Surfaces
Heavy-Duty Steam Rotary Joints & Condensate Syphons
Variable Frequency Drive (VFD) for Adjustable Drum Speed
Micrometer-Adjustable Doctor Blade Scraper Mechanism
Custom Feed Systems (Nip, Dip Pan, Spray, or Multi-Roll Applicator)
Exhaust Hood with Vapor Extraction & Condenser Integration
Sanitary GMP / CGMP Hygienic Construction
PLC-Based Automation with HMI Touchscreen
ATEX / Flameproof / Explosion-Proof Options Available
Construction Materials
Available in high-grade materials certified for food, pharmaceutical, and aggressive chemical duty:
Stainless Steel SS304 / SS304L
Stainless Steel SS316 / SS316L
Duplex & Super Duplex Stainless Steel
Chrome-Plated Fine-Grain Cast Iron / Alloy Steel
Hastelloy & Nickel Alloys
Abrasion-Resistant Claddings
Heating Media
Saturated Steam
Superheated Steam
Thermal Oil / Hot Oil Systems
Electrical Heating (For Specialized R&D / Pilot Units)
Industries We Serve
Starch & Starch Derivatives
Food & Beverage Processing
Dairy & Dairy Ingredients
Chemical Processing
Pharmaceuticals & Biotech
Effluent Treatment (ETP) / ZLD Plants
Distilleries & Breweries
Animal Feed & Agrochemicals
Pulp, Paper & Biomass
Mining & Minerals Processing
Applications of Drum Dryers
GTI Single and Double Drum Dryers are widely utilized across demanding process industries:
Starch & Food Industry
Pre-gelatinized Starch
Potato Flakes & Granules
Baby Food & Cereal Flakes
Milk Powder & Whey Derivatives
Malted Milk Mixes
Fruit Purees & Tomato Paste
Vegetable Concentrates
Yeast Extracts & Baker’s Yeast
Gelatin & Hydrolyzed Proteins
Coffee & Tea Extracts
Chemical & Petrochemical Industry
Sodium Silicate
Calcium Chloride
Detergent Powders
Industrial Salts & Nitrates
Dyes, Pigments & Intermediates
Synthetic Polymers & Resins
Agrochemicals & Pesticides
Catalysts & Silica Gel
Barium Compounds
Environmental & Waste Recycling (ZLD)
Zero Liquid Discharge (ZLD) Effluent Drying
Industrial Wastewater Sludge
Hazardous Waste Sludge
Distilleries Spent Wash Concentrate
Textile Effluent Salts
Digested Organic Sludge
Electroplating Effluent Concentrate
Ethanol, Brewery & Distilleries
Distillers Solubles (Condensed Distillers Solubles)
Brewer’s Spent Grain Slurry
Fermentation Residues
Ethanol By-product Concentrates
Pharmaceutical & Biotechnology
Active Pharmaceutical Ingredients (APIs)
Botanical & Herbal Extracts
Fermentation Broths
Antibiotic Extracts
Biological Powders
Marine Extracts (Algae / Kelp)
Animal Feed & Agriculture
Feed Yeast
Whey Powder for Calf Milk Replacers
Soluble Fish Protein / Fish Solubles
Blood Meal
Slaughterhouse Waste Processing
Molasses By-products
Why Choose GTI Drum Dryers?
GTI Technologies designs every Single and Double Drum Dryer custom-tailored to the specific rheology, heat sensitivity, initial moisture, and required output of your feed slurry. We offer:
In-House Lab & Pilot Testing: Determine exact evaporation rates, drying speed, and flaking characteristics.
Custom Engineering: Tailor drum dimensions, scraper geometry, and metallurgy to your product.
Turnkey Delivery: From design and fabrication to piping, automation, installation, and commissioning.
Global Export Standard: Built in compliance with ASME, CE, GMP, and international quality standards.
Lifetime Support: Complete technical service, spare parts supply, and process optimization.
Frequently Asked Questions (FAQs)
What is the difference between a Single Drum Dryer and a Double Drum Dryer?
A Single Drum Dryer uses one drum with specialized applicator rollers or dip pans, ideal for viscous, sticky, or gelatinized products. A Double Drum Dryer uses two counter-rotating drums with a central feed nip, making it highly efficient for low-to-medium viscosity solutions and slurries.
Why choose a Drum Dryer over a Spray Dryer?
Drum Dryers require significantly less thermal energy and air handling, occupy a much smaller footprint, can handle highly viscous pastes that clog spray nozzles, and deliver a unique flake/powder texture ideal for instant food products and concentrated industrial salts.
What materials are best suited for Drum Drying?
Any liquid, solution, suspension, paste, or slurry with high dissolved or suspended solids, such as pre-gelatinized starches, fruit purees, milk, chemical salts, pharmaceutical extracts, feed yeast, and ZLD industrial sludge.
How is the moisture content controlled on a Drum Dryer?
Moisture content is precisely controlled by adjusting steam pressure (drum surface temperature), drum rotation speed (residence time), film thickness (gap/feed setting), and internal steam condensate evacuation.
